UniFi Switch USW-Pro-48, Capa 3 de 48 puertos Gigabit RJ-45 + 4 puertos 1/10G SFP+, pantalla informativa

UniFi Switch USW-Pro-48, Capa 3 de 48 puertos Gigabit RJ-45 + 4 puertos 1/10G SFP+, pantalla informativa - Imagen 2

UniFi Switch USW-Pro-48, Capa 3 de 48 puertos Gigabit RJ-45 + 4 puertos 1/10G SFP+, pantalla informativa - Imagen 3

UniFi Switch USW-Pro-48, Capa 3 de 48 puertos Gigabit RJ-45 + 4 puertos 1/10G SFP+, pantalla informativa - Imagen 4

UniFi Switch USW-Pro-48, Capa 3 de 48 puertos Gigabit RJ-45 + 4 puertos 1/10G SFP+, pantalla informativa - Imagen 5

UniFi Switch USW-Pro-48, Capa 3 de 48 puertos Gigabit RJ-45 + 4 puertos 1/10G SFP+, pantalla informativa - Imagen 6

UniFi Switch USW-Pro-48, Capa 3 de 48 puertos Gigabit RJ-45 + 4 puertos 1/10G SFP+, pantalla informativa

Name: UniFi Switch USW-Pro-48, Capa 3 de 48 puertos Gigabit RJ-45 + 4 puertos 1/10G SFP+, pantalla informativa - Globaltecnoly
SKU: USW-PRO-48
Price: 3965758 COP
Availability: InStock

$ 3.965.758

Características Principales:

Puertos SFP+ 10G
Ventiladores integrados para enfriamiento casi silencioso
Capa 3 (* Disponible en una futura versiÃ³n de firmware)
Entrada DC UniFi SmartPower RPS

6 disponibles

SKU: USW-PRO-48 Categorías: Redes, REDES E INTERNET Marca: UBIQUITI

Technical Specifications

Overview

Dimensions

442 x 285 x 44 mm (17.4 x 11.2 x 1.7′)

Port Layout

1 GbE RJ45

48 (1G/100M/10M)

10G SFP+

4 (10G/1G)

Redundancy

DC Power Backup

Layer 3

Yes

Form Factor

Rack mount (1U)

Performance

Switching Capacity

176 Gbps

Total Non-Blocking Throughput

88 Gbps

Forwarding Rate

131 Mpps

Supported VLANs

1,000

MAC Address Table Size

16,000

L3 Table Size

ARP Entries

4,000

IPv4 Routes

1,000

IPv4 Static Routes

256

Packet Buffer Size

4 MB

Access Lists

IPv4

128

MAC

128

Layer 3 Features

DHCP Server (Local Networks)

Yes

DHCP Relay

Yes

Inter-VLAN Routing (Local Networks)

Yes

Static Routing (Local Networks)

Yes

Layer 2 Features

LACP Port Aggregation

Yes

STP & RSTP

Yes

QoS (DSCP)

Yes

Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron)

Yes

Advanced IGMP Configuration (Querier, Fast Leave, Router Port)

Yes

IGMP Snooping

Yes

802.1X Control

Yes

MAC-Based ACLs & Device Isolation

Yes

DHCP Snooping & Guarding

Yes

Egress Rate Limit

Yes

Flow Control

Yes

Storm Control

Yes

Multicast & Broadcast Rate Limiting

Yes

MAC Address Blocking

Yes

IP-Based ACLs & Network Isolation

Yes

MAC-Based Port Restriction

Yes

Port Isolation

Yes

Port Mirroring

Yes

Jumbo Frames

Yes

LLDP-MED

Yes

Voice VLAN

Yes

Loop Protection

Yes

Virtual Network Override

Yes

Hardware

Max. Power Consumption

60W

Power Method

(1) Universal input, 100—240V AC, 50/60 Hz (1) USP RPS DC input

Power Input Method

AC input

Power Supply

AC/DC, internal, 60W

Supported Voltage Range

100—240V AC

Management

Ethernet AR

Heat Dissipation

204.7 BTU/hr

Weight

Without mounting brackets: 4 kg (8.8 lb) With mounting brackets: 4.1 kg (9 lb)

Enclosure Material

SGCC steel

Mount Material

SGCC steel

Supported Rack Depth

400~1200 mm (15.7-47.2′)

LCM Display

1.3′ touchscreen

ESD Protection

Air: ± 16kV, contact: ± 12kV

Ambient Operating Temperature

-5 to 40° C (23 to 104° F)

Ambient Operating Humidity

10 to 90% noncondensing

NDAA Compliant

Yes

Certifications

CE, FCC, IC, Anatel: 00469-21-08356

Software

Application Requirements

UniFi Network

Version 5.12.11 and later

Peso	6,00 kg
Dimensiones	50 × 40 × 10 cm
