Overview
Dimensions
442 x 120 x 43.7 mm (17.4 x 4.7 x 1.7′)
Port Layout
10G SFP+
8 (10G/1G)
Form Factor
Rack mount (1U)
Performance
Switching Capacity
160 Gbps
Total Non-Blocking Throughput
80 Gbps
Forwarding Rate
119 Mpps
Supported VLANs
1,000
MAC Address Table Size
16,000
Packet Buffer Size
1.5 MB
Access Lists
IPv4
128
MAC
128
Layer 2 Features
LACP Port Aggregation
Yes
STP & RSTP
Yes
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
Yes
IGMP Snooping
Yes
802.1X Control
Yes
MAC-Based ACLs & Device Isolation
Yes
DHCP Snooping & Guarding
Yes
Egress Rate Limit
Yes
Flow Control
Yes
Storm Control
Yes
Multicast & Broadcast Rate Limiting
Yes
MAC Address Blocking
Yes
IP-Based ACLs & Network Isolation
Yes
MAC-Based Port Restriction
Yes
Port Isolation
Yes
Port Mirroring
Yes
Jumbo Frames
Yes
LLDP-MED
Yes
Voice VLAN
Yes
Loop Protection
Yes
Virtual Network Override
Yes
Hardware
Max. Power Consumption
36W (Including SFP modules)
Power Method
Universal input, 100—240V AC, 50/60 Hz
Power Input Method
AC input
Power Supply
AC/DC, internal, 36W
Supported Voltage Range
100—240V AC
Management
Ethernet AR
Heat Dissipation
102 BTU/hr
Weight
Without mounting brackets: 2.6 kg (5.8 lb) With mounting brackets: 2.7 kg (6 lb)
Enclosure Material
SGCC steel
Mount Material
SGCC steel
Supported Rack Depth
400~1200 mm (15.7-47.2′)
LCM Display
1.3′ touchscreen
ESD Protection
Air: ± 16kV, contact: ± 12kV
Ambient Operating Temperature
-5 to 40° C (23 to 104° F)
Ambient Operating Humidity
10 to 90% noncondensing
NDAA Compliant
Yes
Certifications
CE, FCC, IC, Anatel: 04456-21-08356
Software
Application Requirements
UniFi Network
Version 5.14.12 and later
| Peso | 2,20 kg |
|---|---|
| Dimensiones | - × - × - cm |
